RK3566 SBC Custom Solutions for Portable Monitors and Android All-in-One Devices
Home >> Solution >> SBC

PRODUCT DETAIL

PMDP3566
project-left
project-left
  • RK3566 SBC Custom Solutions for Portable Monitors and Android All-in-One Devices LPDDR4 2G/3G/4G/6G/8G
    SOC
    LPDDR4 2G/3G/4G/6G/8G
  • RK3566 SBC Custom Solutions for Portable Monitors and Android All-in-One Devices WiFi5,802.11a/b/g/n/ac<br>Bluetooth 5.0
    Connectivity
    WiFi5,802.11a/b/g/n/ac
    Bluetooth 5.0
  • RK3566 SBC Custom Solutions for Portable Monitors and Android All-in-One Devices 2 x Type-C (PD-Power, DP-IN for PortableMonitor<br>Mode, OTG/ADB for Android Mode)<br>1 x HDMI-IN, mini-hdmi<br>1 x Menu button<br>1 x Wave Wheel Button<br>1 x 3.5mm Headphone
    Interface
    2 x Type-C (PD-Power, DP-IN for PortableMonitor
    Mode, OTG/ADB for Android Mode)
    1 x HDMI-IN, mini-hdmi
    1 x Menu button
    1 x Wave Wheel Button
    1 x 3.5mm Headphone

  • SPECIFICATION

OS Android
SOC RK3566, 4 x Cortex-A55, 1.8GHz, 22nm
GPU ARM G52 2EE, 0.8 TOPS NPU
RAM LPDDR4 2G/3G/4G/6G/8G
ROM EMMC5.1 32G/64G
Media 4K 60fps H.265/H.264/VP9 decode
1080P 100fps H.265/H.264 codec
Display EDP1.3, 1080@60fps
Connectivity WiFi5,802.11a/b/g/n/ac
Bluetooth 5.0
USB TP
Incell-tp or usb-tp
Audio Speaker,2 x 1W
headphone x 1
Interface 2 x Type-C (PD-Power, DP-IN for PortableMonitor
Mode, OTG/ADB for Android Mode)
1 x HDMI-IN, mini-hdmi
1 x Menu button
1 x Wave Wheel Button
1 x 3.5mm Headphone
Input Power DC=5V3A(default)
PD=5V3A/9V3A/12V3A/15V3A (optional)
Environment Operating temperature-20°C ~ 60°C
