D-E6-RCL
project-left
project-left
  • RK3566, 4 x Cortex-A55, 1.8G <br>22nm ARM G52 2EE<br>0.8 TOPS NPU
    SOC
    RK3566, 4 x Cortex-A55, 1.8G
    22nm ARM G52 2EE
    0.8 TOPS NPU
  • WiFi4 802.11b/g/n or 802.11a/b/g/n/ac <br>Bluetooth 4.2 or 5.0
    Connectivity
    WiFi4 802.11b/g/n or 802.11a/b/g/n/ac
    Bluetooth 4.2 or 5.0
  • 40Pin GPIO extension:<br>UART/I2C/SPI/PCM/PWM/ADC/GPIO etc.
    Interface
    40Pin GPIO extension:
    UART/I2C/SPI/PCM/PWM/ADC/GPIO etc.
  • SPECIFICATION
OS Android 11/Debian/Buildroot/Ubuntu
SOC RK3566, 4 x Cortex-A55, 1.8GHz, 22nm ARM G52 2EE, 0.8 TOPS NPU
RAM LPDDR4 2G/3G/4G/6G/8G
ROM EMMC5.1 8GB/16G/32G/64G/128G
Media 4K 60fps H.265/H.264/VP9 decode 1080P 100fps H.265/H.264 codec
Display MIPI-DSI display port, 2-Lane
Micro-HDMI port (up to 4Kp60 supported) 4-lane MIPI CSI, Camera interface
Ethernet Gigabit Ethernet port (supports PoE with add-on PoE HAT)
Connectivity WiFi4 802.11b/g/n or 802.11a/b/g/n/ac, Bluetooth 4.2 or 5.0
USB USB2.0 x 1 (Type C) OTG
USB3.0 x 1 (Type A)
USB2.0 x 2 (Type A)
TF-Card Micro SD card, up to 128GB
Audio Spearker: /
Headset: 3.5mm Earphone
Mic: MIC Input
Interface 40Pin GPIO extension: UART/I2C/SPI/PCM/PWM/ADC/GPIO etc.
Input Power 5V DC via USB C connector 5V DC via GPIO header
Power over Ethernet (requires separate PoE HAT)
PCB Size: 56 x 85 x 1.6mm
Process: 6-layers Immersion
Gold Hole: ∮2.5mm x 4
Environment Operating temperature -20°C ~ 60°C
