| OS | Android |
| SOC | RK3566, 4 x Cortex-A55, 1.8G, 22nm ARM G52 2EE, 0.8 TOPS NPU |
| RAM | LPDDR4 2G/4G/6G/8G |
| ROM | EMMC5.1 32G/64G/128G |
| Media | 4K 60fps H.265/H.264/VP9 decode 1080P 100fps H.265/H.264 codec |
| Display | HDMI2.0 port (4Kp60) |
| Ethernet | NA |
| Connectivity | WIFI6 802.11a/b/g/n/ac，Bluetooth5.0 |
| USB | USB3.0 x 1(with OTG) |
| TF-Card | Micro SD card,up to 128GB |
| Audio | HDMI audio out |
| Interface | 4-lane mipi Camera,5MP@30fps HDR UART/USB/ADC/KEY/VBAT via 40Pin-FPC |
| Input Power | VBAT 3.8V via 40Pin-FPC |
| PCB | Size: 95 x 64 x 1.0mm Process: 6-layer HDI Immersion Gold Package:LCC134 |
| Environment | Operating temperature -20°C ~ 60°C |
