| OS | Android |
| SOC | RK3588 4 x Cortex-A76 + 4 x Cortex-A55 2.4GHz，8nm 6.0TOPS NPU, Support INT4/INT8/INT16 |
| RAM | LPDDR4 4GB/8GB/16GB/32GB |
| ROM | EMMC5.1 64G/128G |
| Media | Video decoding: 8K@60fps H.265/VP9/AVS2 8K@30fps H.264 AVC/MVC 4K@60fps AV1 |
| Display | Supports up to 5 screens with different displays, tactile sensations and sounds. HDMI2.1 out or HDMI convert to VbyOne 4K@60fps DP1.4 convert to Dual-LVDS 1080@60fps DP1.4 convert to Dual-LVDS 1080@60fps 4-Lane MIPI-DSI convert to Dual-LVDS 1080@60fps 4-Lane MIPI-DSI convert to Dual-LVDS 1080@60fps |
| Ethernet | Supports up to 5 screens with different displays, tactile sensations and sounds. HDMI2.1 out or HDMI convert to VbyOne 4K@60fps DP1.4 convert to Dual-LVDS 1080@60fps DP1.4 convert to Dual-LVDS 1080@60fps 4-Lane MIPI-DSI convert to Dual-LVDS 1080@60fps 4-Lane MIPI-DSI convert to Dual-LVDS 1080@60fps |
| Connectivity | WIFI6 802.11a/b/g/n/ac/ax，Bluetooth5.0，2T2R |
| USB | USB2.0 x 5 for USB-TP USB2.0（with OTG）x 1 for update USB2.0 x 1 for 4G module USB2.0 x 3 host |
| Audio | Spearker: 10 speaker total 10W x 2 Stereo 3W x 2 Stereo 3W x 2 Stereo 3W x 2 Stereo 3W x 2 Stereo |
| Interface | 2 x RS485 for motor control Key interface |
| Input Power | DC-12V via 8pin-PH2.54 |
| PCB | Size: 180 x 180 x 1.6mm Process: 4-layer Immersion Gold |
| Environment | Operating temperature -20°C ~ 60°C |
