| OS | Android |
| SOC | RK3588 4 x Cortex-A76 + 4 x Cortex-A55 2.4GHz，8nm 6.0TOPS NPU, Support INT4/INT8/INT16 |
| RAM | LPDDR4 4GB/8GB/16GB/32GB |
| ROM | EMMC5.1 64G/128G |
| Media | Video decoding: 8K@60fps H.265/VP9/AVS2 8K@30fps H.264 AVC/MVC 4K@60fps AV1 |
| Display | HDMI out, HDMI2.1,up to 8K@60Hz HDMI in, HDMI 2.0 RX PHY,4-lanes,up to 4K@60Hz eDP1.3, 4Lane, 4K@60Hz DP1.4 output, 4-Lane x 2 2 x 4-Lane or 1 x 8-Lane MIPI-DSI,LCD interface |
| Ethernet | Gigabit Ethernet interface x 2（The carrier board） |
| Connectivity | WIFI6 802.11a/b/g/n/ac/ax，Bluetooth5.0，2T2R（The carrier board） |
| USB | USB3.1 OTG x 2 USB 3.0 x 2 USB2.0 x 2 |
| TF-Card | Micro SD card,up to 128GB（The carrier board） |
| Audio | Can be customized |
| Interface | PCIe3.0(2 x 2lanes,1 x 4lanes,4 x 1lanes) PCIE2.1(1 1anes) x 3 SATA3.0 x 3 4lane Mipi-CSI UART/I2C/SPI/PCM/PWM/ADC/SDMMC/GPIO |
| PCB | The carrier board can be customized |
| Environment | Operating temperature -20°C ~ 60°C |
